Z2 54P
The Cub Cadet® Ultima Series Z2 54P 54-in. 23 HP*/726cc Zero-Turn Lawn Mower with AeroForce™ Fabricated Deck is designed to deliver uncompromised performance, durable strength, and proven results. Built with premium comfort features engineered to provide the ultimate mowing experience this mower helps you tackle hills and slopes up to 15-degrees. Save time mowing with an Ultima Series™ zero-turn, 25% faster than a tractor**
- The Ultimate Mowing Experience from Cub Cadet® is powered by a reliable 23 HP*/726cc Kawasaki® Engine.
- An AeroForce™ welded, heavy-duty fabricated deck delivers a signature cut with few clumps and stragglers, fine clippings and evenness.
- Protect against wear and tear while being the envy of your neighborhood with a continuous, 2×2 tubular steel frame designed to withstand heavy loads and provide stability on rough, uneven terrain
- Mow comfortably with 20 in. high back, luxury seat bolstered using custom foam designed to minimize vibration.
Engine
- Engine Brand: Kawasaki®
- Engine Model: FR Series
- Engine Model Number: 691V
- Engine Displacement: 726cc
- Engine Output: 23 HP
- Starter Type: Electric
- Fuel Tank Capacity: 3.5 gal. US (13.25 L)
- Cylinders: Twin
- Engine Start: Ignition Key
- Engine Oil Capacity: 2.1 qts. US
- Lubrication: Fully pressurized
- Charging System: 12 amp regulated
- Fuel Gauge: No
- Governor:Mechanical
- Choke: Separate Choke
- Air Filter: Single element
- Oil Filter: Yes
- Fuel Delivery: Carburetor
Battery
- Battery: 230 CCA
- Battery Type: Lead Acid
- Battery Voltage: 12V
Drive System
- Transmission: Hydro-Gear EZT 2200
- Forward Speed: 7 MPH / 11.3 km/h
- Reverse Speed: 3.5 MPH / 5.6 km/h
- Drive System: Hydrostatic
Cutting Deck
- Deck Cutting Width: 54 in
- Deck Wash: No
- Deck Material: 11-gauge steel
- Deck Engagement: (PTO) Electric
- Deck Construction: Fabricated
- Blade(s): Three
- Deck Lift: Foot pedal with Dial Adjust
- Cutting Height Range: 1” – 4.5”
- Anti-Scalping: Two gauge wheels
- Deck Positions: 15
Warranty
- Residential Warranty: 3-year unlimited hours
- Frame Warranty: Lifetime Limited
- Deck Shell Warranty: Lifetime Limited
Chassis
- Frame: 2” x 2” tubular steel
- Turning Radius: 0°
- ROPS: No
- Rear Tow Hitch: Yes
- Corrosion Protection: Yes
Controls
- Cruise Control: No
- Steering Control: Lap Bars
- Handle Grip(s): Ergonomic Overmolded Soft Touch
- Brakes: Disc
Comfort
- Seat Type: 20? Cut-and-Sew with Head Bolster
- Armrests: No
- Seat Adjustment: Knob
Wheels
- Rear Tires: 20”x 10”-8?
- Front Tires:11?x 6?-5?
- Tire Tread: Turf Armor
Additional Specifications
- Hour Meter: Yes
- Headlight(s): LED Lightbar
- Cup Holder: Yes
- Operator Presence System: Yes
- Parking Brake: Lap Bar Integrated
- Model Number:17FIEAEM010
- AIR FILTER: KM-11013-0752
- OIL FILTER: KM-49065-0736
- FUEL FILTER: KM-49019-0031
- SPARK PLUG: KM-BPR4ES
- DECK BELT : 954-04329A
- DRIVE BELT: 954-04317A OR 490-501-C069
- BLADES: 742P05086
- XTREME BLADES: 742P05086-X
- IGNITION KEY: 925-1745A
- HOUR METER KIT:
