SET UP AND PREP FEES MAY APPLY
- A strong 20 HP Kohler® engine delivers reliable power to tackle your yard.
- 42-in. heavy-duty fabricated AeroForce™ deck cutting system delivers a best-in-class cut with fewer clumps, finer clippings and increased evenness
- Tuff Torq Hydrostatic transmission, no shifting, just push the pedal and go.
Engine
- Engine: Kohler KT720
- Engine Displacement: 747cc
- Fuel Tank Capacity: 3.0 gal.
- Cylinders/Material: Twin Cast Iron
- Engine Start: Key
- Engine Oil Capacity: 2 qts.
- Lubrication: Fully pressurized
- Battery: 12V 210 cold crank amps AGM
- Charging System: 12 Amp Regulated
- Fuel Gauge: Fuel sight window
- Governor: Manual
- Choke: Separate Choke
- Air Filter: Single element
- Oil Filter: Yes
Drive System
- Transmission: Hydrostatic, foot
- Forward Speed: 5.5 MPH
- Reverse Speed: 3 MPH
- Rear Axle: 3/4? w/dual PM steel drive hubs
- Transmission Housing: Cast aluminum
- Transmission Type: Tuff Torq K46
Cutting Deck
- Deck Cutting Width: 42?
- Cutting Modes: Discharge/mulch/bagging
- Deck Wash: Included
- Deck Attach/Removal: QuickAttach™ (no tools required)
- Deck Engagement (PTO): Manual lever
- Blade(s): 2
- Deck Lift: Lever/spring assisted
- Cutting Height Range: 1? – 4?
- Anti-Scalping: 2 ball
- Deck Positions: 12 positions
Chassis
- Frame: Robotically welded
- Front Axle(s): Heavy duty Cast iron
- Turning Radius: 16?
- Front Tires: 15?x6?-6?
- Rear Tires: 20?x8?-8?
- Tire Tread: Multi-Trac
- Rear Tow Hitch: Included
- Corrosion Protection: E-coating
Controls
- Cruise Control: Yes
- Brakes: Disc
- Direction: NEW optimized steering system, manual sector and pinion
- Headlight(s): 2 – LED High Illumination
- Display Hour meter
Comfort
- Seat Type: Cub Comfort™ high-back seat
- Arm Rests: Comfort
- Seat Suspension: Seat spring
- Seat Adjustment: Lever
- Floor Mats: Traction Pad
- Seat adj: 10 degree incline and slide
Additional Specifications
- Mulch Kit: Optional
- Discharge Chute: Included
- Cup Holder: Included
- Operator Presence System: Included
- Bagger: Optional
- AIR FILTER: 16 883 04-S1 OR 490-200-K059
- OIL FILTER: 12 050 01-S
- ENGINE Oil: 25 357 26-S OR 490-000-C044
- TRANS FLUID: TT-187Q0899000
- FUEL FILTER: 24 050 13-S1
- SPARK PLUG: 25 132 12-S OR RC12YC
- DECK BELT: 954-05021 OR 490-501-C062
- DRIVE BELT: 954-05027B OR 490-501-C061
- BLADES ORDER 2: 742P05177 OR SET 490-110-C191
- XTREME BLADES: 742P05177A-X OR SET 490-110-C202
- IGNITION KEY: 925-1745A
Warranty
- Warranty: 3-year unlimited hours
- Frame Warranty: 5-year limited
- Front Axle Warranty: 5-year unlimited hours
- Deck Shell Warranty: Lifetime limited
- Commercial Warranty: No
