The Ranger R76ATR 220V Tilt-Back Tire Changer is a professional-grade tire service machine engineered for automotive repair shops, tire centers, dealerships, performance garages, and other demanding wheel-service environments.
Featuring a 30-inch clamping capacity, tilt-back tower, right-side single assist tower, RimGuard™ wheel clamps, pneumatic bead breaker, and TurboBlast™ bead-seating system, the R76ATR provides the control and versatility needed to service conventional, low-profile, performance, and run-flat tires.
This SKU 5140140 configuration is powered by a 3 HP, 208–240V, 50/60Hz, single-phase electric motor.
Tilt-Back Tower Design
The R76ATR features a professional tilt-back tower that moves away from the wheel during loading and unloading.
This design provides additional working clearance and helps reduce repeated tool-head adjustments when technicians move between different wheel sizes.
Right-Side Single Assist Tower
A single right-side power assist tower comes standard on the R76ATR.
The assist system provides additional control over difficult tire beads and stiff sidewalls, making it particularly useful when servicing:
- Low-profile tires
- Run-flat tires
- Performance tires
- Stiff-sidewall tires
- Difficult tire and wheel combinations
The assist system incorporates a traveling drop-center hold-down device and bead-assist tools to help keep the tire bead properly positioned during mounting and demounting.
30-Inch Wheel Capacity
Ranger’s adjustable RimGuard™ wheel clamps provide a broad wheel-service range.
- Internal Clamping Range: 10–30 in.
- External Clamping Range: 9–28 in.
The four-clamp system uses dual pneumatic cylinders to provide secure and consistent wheel positioning during tire service.
High-Power 3 HP Turntable
The 220V R76ATR uses a powerful 3 HP electric turntable motor designed for professional tire-service applications.
The electric/air drive system provides controlled turntable operation when mounting and demounting conventional and difficult tire assemblies.
TurboBlast™ Bead-Seating System
The integrated TurboBlast™ bead-seating system delivers a high-volume burst of air to help establish the initial seal between the tire bead and wheel during inflation.
This is especially useful when servicing tires where conventional inflation alone does not immediately seat the bead.
Adjustable Pneumatic Bead Breaker
A powerful pneumatic bead-breaking system uses an adjustable blade to help separate tire beads from the rim.
The adjustable configuration allows technicians to position the bead-breaker blade appropriately for different wheel and tire combinations.
Large Tire Capacity
The R76ATR handles tires measuring up to 43 inches in overall diameter.
The turntable accommodates tire widths from approximately 4 to 18 inches during mounting, providing useful capacity for passenger cars, SUVs, pickups, and compatible light-truck applications.
Key Features
- Professional tilt-back tire changer
- SKU 5140140
- 3 HP electric motor
- 208–240V, 50/60Hz, single-phase
- 30-inch maximum internal clamping capacity
- Right-side single power assist tower
- Tilt-back main tower
- RimGuard™ wheel clamps
- Four-clamp internal/external system
- Dual pneumatic clamping cylinders
- 10–30 in. internal clamping range
- 9–28 in. external clamping range
- Maximum tire diameter of 43 in.
- Up to 18 in. turntable tire-width capacity
- Adjustable pneumatic bead breaker
- TurboBlast™ bead-seating system
- Pneumatic locking tool head
- Traveling drop-center hold-down device
- Upper bead-assist roller
- Lower bead-lifting assistance
- Nylon non-marring wheel restraint
- Electric / pneumatic drive system
- Designed for professional tire-service applications
Product Specifications
- Brand: Ranger Products
- Model: R76ATR
- SKU: 5140140
- Product Type: Tilt-Back Tire Changer with Single Assist Tower
- Motor: 3 HP
- Voltage: 208–240V
- Frequency: 50/60Hz
- Phase: Single Phase
- Drive System: Electric / Air
- Wheel Clamping: 4 Clamps – Internal / External
- Internal Clamping Range: 10–30 in.
- External Clamping Range: 9–28 in.
- Maximum Tire Diameter: 43 in.
- Maximum Wheel Width: 15 in.
- Turntable Tire Width Capacity: 4–18 in.
- Tower Design: Tilt-Back
- Assist Tower: Single / Right-Side
- Table Clamping System: Dual Pneumatic Cylinders
- Bead Breaker: Adjustable Pneumatic Blade
- Bead-Seating System: TurboBlast™
- Air Requirement: 140–165 PSI
- Shipping Dimensions: Approx. 50 × 50 × 68 in.
- Shipping Weight: Approx. 920 lbs.
- Shipping Method: LTL Freight
Standard Equipment
- Right-Side Single Assist Tower
- Traveling Drop-Center Hold-Down Device
- Bead Assist Tools
- TurboBlast™ Bead-Seating System
- Inflation System
- Inflation Gauge with Air Dump Valve
- Inflation Pressure Regulator / Limiter
- Alloy-Steel Mount/Demount Head
- Nylon Mount/Demount Head
- Air Regulator
- Water Filter
- Oiler / Lubricator
- Bead Tool / Tire Iron
- Lubricant Bucket
- Lubricant Brush
- Tool Storage
